22.5x8.25 Forged Aluminum Alcoa Style Rim
$265.00
Upgrade your truck’s performance and appearance with this 22.5 x 8.25 forged aluminum Alcoa-style rim, engineered for heavy-duty commercial use. Built from high-strength 6061-T6 forged aluminum, this wheel delivers superior durability while remaining significantly lighter than traditional steel rims—helping improve fuel efficiency and payload capacity.
| Specification | Details |
|---|---|
| Wheel Size | 22.5 x 8.25 inches |
| Material | Forged Aluminum (6061-T6) |
| Construction | One-Piece Forged |
| Finish | Polished / Alcoa-Style |
| Bolt Pattern | 10-Lug (Hub-Piloted) |
| Bolt Circle Diameter | 285.75 mm (11.25") |
| Offset | Standard / Hub-Piloted Offset |
| Center Bore | 220 mm (Approx.) |
| Valve Stem Hole | Standard Metal Valve Compatible |
| Load Rating | Up to 7,400 lbs (varies by manufacturer) |
| Weight | Approx. 45–50 lbs |
| Mount Type | Hub-Piloted (Stud-Piloted options available) |
| Application | Steer / Drive / Trailer Positions |
| Compatible Tire Size | 22.5” Commercial Truck Tires |
| Corrosion Resistance | High (Polished Aluminum Finish) |
| Certifications | DOT / SAE Compliant |
